The IPTV Set-Top box MAG420 is perfect for people who want to watch video content in the highest quality. Thanks to this device, you can enjoy an unmatchable Ultra HD picture at 60 FPS framerate combined with 6-channel Dolby Digital audio.
STANDARD SET
To start using the STB, no additional purchases are required: the device comes pre-equipped with a user manual, a power adapter, an HDMI 2.0 cable, and a remote control with 2 AAA batteries. We do our best to make sure you get the most out of your purchase!
THE NEWEST IMAGE QUALITY STANDARDS AT YOUR FINGERTIPS
With this IPTV Set-Top Box, you will be able to watch Ultra HD video content at 60 FPS framerate without the slightest delay. Thanks to its powerful Quad-Core processor, MAG420 always provides the smoothest picture possible. With this IPTV STB, you will completely forget lagging issues even exist once and for all! No more freezing or buffering.
HEVC: PLAYBACK WITHOUT ARTIFACTS
The MAG420 supports HEVC technology, which offers much better data compression than any other existing codec. Thanks to HEVC, the STB downloads content twice as fast as devices using H.264. Not only that, but video compressed using this standard contains significantly fewer compression defects.
To top it all, HEVC can play any video or audio formats that your TV supports, and deliver 4K video-content even if your connection is slow.
BOTH SIMPLE AND UNIVERSAL
The MAG420 is easy to install and operate: connecting and setting up the set-top box will take you no more than 10 minutes. Simply connect the device to the TV using an HDMI or RCA cable, and to the Internet with an Ethernet cable. Place the device on a hard, non-slippery surface in a dry place and make sure that it is well ventilated from all sides. Follow these simple instructions – and the MAG420 will be sure to give you many hours of high-quality viewing experience!
Dimensions
Width/depth/height, (mm)
132х87х26
Weight, g
128
Hardware
Chipset
Hi3798MV200
Processor
ARM Cortex-A53 Quad Core CPU 1200 MHz
Performance
15 000 DMIPS
RAM
512 MB
Flash memory
512 MB NAND
Software
Operating system
Linux 4.4.35
Middleware supported
Ministra TV platform version 5.4.1 or higher
Interfaces
RCA 3.5 mm, HDMI 2.0, Ethernet 100 Mbps, USB 2.0х1, USB 3.0x1
Sources of media content
PC and NAS in a local network, Stream media protocols (RTSP, RTP, UDP, HTTP), USB devices
Audio & video
Audio сodecs
MPEG L1/L2/L3, Dolby Digital, AAC-LC, HE AAC V1/V2, APE, FLAC
Audio formats
AC3, ACC, APE, FLAC, M4A, MP3, OGG, WAV
Video modes
PAL, NTSC, 576p, 720p, 1080p, 1080i, 2160p
Video сodecs
MPEG1/2 MP@HL, MPEG4 part 2 (ASP),H.265 Main/Main 10@L5.1 High 2160p@60 fps (optional), H.264 AVC High@L5.1 2160p@30 fps, XviD, 3D video support
